36CFO-Y
36CFO-Y
Features
Specifications
- Blade Color
- Metallic
- Brand
- Schaefer
- Cfm/watt (@0.10")
- TBD
- Rpm 60 Hz Motor
- 1000-1200
- Drive
- Direct
- Enclosure
- TEAO
- Frame Size
- 48YZ
- Phase
- 1
- Speeds
- 2
- Vfd Compatible
- No
- Cfm/watt (free Air)
- 23.3
- Cord
- Included - Wired
- Diameter (inches)
- 36
- Frequency (hz)
- 60
- Guard Color
- Yellow
- Nameplate Amps
- 5.2
- Number Of Wings
- 3
- Cfm/watt (@0.05")
- TBD
- Power (hp)
- 1/2
- Product Dimensions (l X W X H Inches)
- 40 3/8 x 40 3/8 x 14.5
- Product Net Weight (lbs)
- 59
- Performance Test #
- 675
- Switch
- On product
- Voltage
- 115
- Maximum Rpm
- 1075
- Blade Material
- Aluminum
- Cfm (high)
- 12120
- Cfm Calculation Standard
- ANSI/AMCA Standard 230-99
- Product Color
- White
- Product Shipping Dimensions (in)
- 41 X 41 X 15
- Speed Control Compatible?
- No
- Able To Ship Small Parcel
- No
- Cfm (low)
- 8750
- Cfm Range (free Air)
- 10001 - 15000
- Cord Length (feet)
- 10
- Fixed Or Portable
- Fixed
- Guard Material
- Powder Coated Steel
- Oscillating
- No
- Country Of Origin
- US
- Guard Spacing (inches)
- 1/2 OSHA
